Description

Make: Ford
Engine: 5.2L MOD Voodoo
Bore: 3.700″ Bore
Stroke: 3.661″ Stroke
Rod Length: 5.933″ Rod
Crown Volume: 7.5cc Dome
Compression Height: 1.155″
Pin Diameter: .827″ Pin
Piston Material: Forged
Ring Lands: 1.2, 1.2, 2.0mm
Top Ring Type: AP Steel
Second Ring Type: Napier
Oil Ring Tension: Standard Tension
Quantity: Sold As Set (8/pkg)
Forced pin oilers from the oil ring
Pin Fitted
Moly Coated Skirts
3D Pockets
Inboard Forging
Pins, Lock’s & Support Rails (if required) included
