Description
BrandMotion Wireless Transparent Trailer® System for RAM 1500 (2009-2018) & Heavy Duty (2010-Current)
TRNS-2170
Not being able to see behind your trailer is a thing of the past. The first-of-its-kind Brandmotion Transparent Trailer system provides a continuous high-definition video feed to your digital rearview mirror, enhancing safety, increasing confidence, and reducing stress while pulling trailers or hauling cargo.
What does the system allow you to do?
- See behind the trailer at all times – not just while in reverse – with HD-quality video. See if you’re being tailgated or when a vehicle is about to pass you.
- Watch the front of the trailer through the integrated third brake light cargo bed camera. Want a quick check on your boat, camper, or horse trailer? Simply touch the bottom of the mirror to switch camera views.
- Capture excellent daily utility beyond towing by watching your pickup bed cargo at all times AND eliminating blind spots around the rear of your truck when not towing.
- Every system component looks factory-integrated thanks to vehicle-specific third brake light cargo bed cameras.
- Thanks to the wireless trailer camera that snaps into most existing trailer camera brackets, installation of the entire system is simple, with no hole-drilling or loss of vehicle features (professional installation recommended).
Features
Integration
Integrates Into Your Specific Truck And Trailer
Heavy Duty Design For Increased Durability
Ultra High Quality Truck-To-Trailer Quick Disconnect Wiring
Easy to Install
Camera Specifications
Industrial Grade CMOS Camera
Camera Dimensions: 2.5″ Wide x 2.2″ Deep x 2.3″ Tall (Bracket Adds 1.5″ Height)
Included Harnessing
1920 x 1080 Resolution 1080p
0.1 Lux With Infrared For Better Illumination And A Sharper Image
Parking Gridlines Available
Format: NTSC
9-16V Operating Voltage Range
Color Image With Automatic White Balance
Electric Auto Iris
170º Horizontal Field of View
130º Vertical Field of View
Waterproof and Shockproof Case
IP 68 Equivalent
Wireless Camera Specifications
1280 x 1080 Resolution
9-16 V Operating Voltage Range
130 Degree Wide Viewing Angle
Shockproof Case
IP68 Equivalent
Night Vision Up To 16m
Mirror Specifications
Large, Vibrant 9.66″ Full-Color Display
1980 x 320 Resolution 1080p
9.66″ Mirror With Edge To Edge Display Embedded
2 Inputs (4 Pin Aviation)
16:9 Aspect Ratio
Format: NTSC and PAL
12-24V Operating Voltage Range
2 Inputs Selectable Via Bottom Button
Mirror Functionality By Holding Bottom Button
No Parking Gridline Overlay (May Be Supplied By Camera)
Installation
Professional Installation Always Recommended
DIY Installation Estimate: 90-120 Minutes
Professional Installation Estimate: 30-60 Minutes
Compatibility
This Transparent Trailer Rear Vision System is designed for RAM 1500 (2009-2018) & Heavy Duty (2010-Current). This kit has two cameras and a 9.66″ edge-to-edge display mirror as a complete rear vision solution.
This kit is designed to function in various vehicles utilizing a D-Tab Wedge mount. Some vehicles may require an adaptor. Please verify product fits in the desired location before final installation.
This mirror is a non-dimming display mirror.
*Note: If you are requiring a microphone that your OEM mirror contained, please see 5000-PESMVR.
**Note: If you are looking for a transparent trailer system to use a different camera, please see TRNS-2100.
